Documentation

This manual is an Astro Starlight site in docs/ at the repository root. It is built to static HTML, gzip-compressed, staged into internal/docs/dist and embedded into northplaned with go:embed, so every instance — binary, container, edge VM, air-gapped box — serves the manual that matches its own version at /docs/, publicly and offline. The public showcase instance serves it at https://doktrace.com/docs/.

Layout and toolchain

docs/
├── astro.config.mjs          Starlight config: base /docs, plugins, sidebar groups
├── package.json              scripts: dev, build, build:embed, preview
├── compress.mjs              gzip pre-compression for embedding (build:embed)
├── tsconfig.json             extends astro/tsconfigs/strict
├── public/favicon.svg        copied unprocessed by Astro → /docs/favicon.svg
└── src/
    ├── content.config.ts     the `docs` collection (Starlight docsLoader + docsSchema)
    ├── content/docs/         the pages — one directory per sidebar section
    │   ├── index.mdx         landing page (template: splash)
    │   ├── getting-started/  concepts/  monitoring/  alarming/  ai/  ui/
    │   ├── administration/   deployment/  reference/  development/  project/
    ├── assets/
    │   ├── logo.svg          site logo (also the hero image)
    │   ├── openapi.json      spec copy the REST reference is rendered from (`make types`)
    │   └── screenshots/      *.webp UI screenshots (overview.webp, objects.webp, admin-users.webp, …)
    ├── components/
    │   ├── Diagram.astro                 shared frame for inline SVG diagrams
    │   ├── ArchitectureDiagram.astro     the process/request-path diagram (concepts)
    │   ├── AlarmingPipelineDiagram.astro inputs → sources → rules → alerts → escalation → channels (alarming)
    │   └── ProdTopologyDiagram.astro     the np-01 Proxmox topology (deployment)
    └── styles/custom.css     brand accent (Obsidian & Fire), denser tables

Dependencies (docs/package.json): astro 7, @astrojs/starlight 0.41, starlight-openapi (the generated REST reference), starlight-links-validator (build-time link check), starlight-llms-txt (llms.txt exports) and sharp (Astro’s image service). dist/, .astro/ and node_modules/ are git-ignored.

Configuration essentials in astro.config.mjs: site: 'https://doktrace.com' (only for canonical URLs and the sitemap), base: '/docs' (the site lives under that prefix everywhere, which is why every internal link starts with /docs/), logo/favicon/custom CSS, a GitHub social link, editLink.baseUrl pointing at …/edit/main/docs/ (the repository is public, so every page has a working edit link), lastUpdated: false (the Docker build has no .git checkout), pagination on, credits off, table of contents for headings 2–4, and a sidebar of eleven groups each autogenerated from its directory: Getting started, Concepts, Monitoring, Alarming, AI & MCP, User interface, Administration, Deployment, Reference (plus the generated REST API groups), Development, Project. Do not change the sidebar configuration when adding pages — directories and sidebar.order do the work.

Authoring loop

make docs-dev                 # = cd docs && npm run dev  → http://localhost:4321/docs/
cd docs && npm ci             # first time / after a lockfile change
cd docs && npm run build      # full build incl. link validation (what CI runs)
cd docs && npm run preview    # serve the built dist locally

The dev server hot-reloads content, config and components. Two things only exist in a production build: the Pagefind search index (search is disabled in astro dev) and the link validation. make dev does not proxy /docs/ through Vite, and a locally built server only serves /docs/ after make docs — use the Astro dev server while writing.

Pages, frontmatter, sidebar order

A file src/content/docs/<section>/<slug>.md becomes /docs/<section>/<slug>/. Every page starts with:

---
title: Page title
description: One real sentence — it is the search-engine description and the sidebar tooltip.
sidebar:
  order: 3
---

sidebar.order sorts pages inside their autogenerated group (lower first); keep the numbering stable when you insert a page. sidebar.badge: { text: 'New', variant: 'tip' } is available but used sparingly. The landing page index.mdx uses template: splash with a hero block.

Use .md by default. Switch to .mdx only when you need components, and then import them right after the frontmatter:

import { Tabs, TabItem, Steps, Card, CardGrid, LinkCard, FileTree, Badge, Aside } from '@astrojs/starlight/components';

Asides work in both formats:

:::caution[Disabled by default]
A channel created through the API without `enabled: true` never sends.
:::

(note, tip, caution, danger.) Headings start at ## — the # title comes from the frontmatter. Starlight slugifies headings to lower-case hyphenated ids (## Data directory layout → #data-directory-layout), which is what anchor links must use. Tag every code block with a language (bash, yaml, json, go, ini, xml, text, toml, js, ts, sql, dockerfile; Caddyfiles as text) and use title="config.yaml" for file contents; shell examples have no $ prompt so they paste cleanly; secrets are written as <secret> or np_….

MDX pitfalls that fail the build: a bare < or { in prose (put <host> and {{ .event.type }} in backticks or code blocks), <url> autolinks (use [text](url)), HTML comments ({/* */} in .mdx, none in .md), <br> instead of <br />, code fences inside list items indented past the list marker, and an unescaped | inside a table cell (\|).

Components and diagrams

Starlight’s built-ins cover most needs: Tabs/TabItem for the Docker/Compose/binary variants, Steps for procedures, Card/CardGrid/LinkCard for link maps, FileTree for directory listings (see Development setup), Badge, Aside.

Diagrams are inline SVG components in docs/src/components/, not images, so they scale, follow the light/dark theme and are searchable/accessible. Diagram.astro is the shared frame: props title (also the accessible <title> and the id prefix), description (the <desc> and the caption), viewBox, optional maxWidth (default 900px). All colours come from Starlight’s CSS variables; the frame defines element classes box, box-accent, box-soft, t, t-sm, t-muted, t-accent, t-head, edge, edge-accent, and two arrowhead markers whose ids derive from the title slug (#dg-<title-slug>-arrow, #dg-<title-slug>-arrow-accent). The three concrete diagrams compose it:

import ArchitectureDiagram from '../../../components/ArchitectureDiagram.astro';

<ArchitectureDiagram />

To add one, copy ArchitectureDiagram.astro, change the title/viewBox and draw with rect/text/path using the classes above; the page that embeds it must be .mdx.

Screenshots

UI screenshots live in docs/src/assets/screenshots/ as WebP, named after the page or dialog they show (overview.webp, objects.webp, object-detail.webp, alerts-trigger-dialog.webp, admin-users.webp, command-palette.webp, …). Because they sit under src/assets, Astro’s image pipeline (sharp) processes them — optimised, content-hashed into _astro/, with width/height for layout stability. Reference them relative to the page:

![Objects list with the kind filter set to hosts](../../../assets/screenshots/objects.webp)

or in .mdx via import { Image } from 'astro:assets' and import objects from '../../../assets/screenshots/objects.webp', then <Image src={objects} alt="…" />. Always write a real alt text. Do not drop images into public/ — they would bypass optimisation and need the /docs/ prefix spelled out by hand. The screenshots are inserted by the documentation lead; writers leave a one-line placeholder note rather than adding images themselves.

Links and the validator

Every internal link is absolute and carries the base: /docs/<section>/<slug>/ with the trailing slash, anchors as /docs/<section>/<slug>/#heading-id, external links as full https:// URLs. The build runs starlight-links-validator with errorOnRelativeLinks: false and errorOnInvalidHashes: true: a link to a page that does not exist or to a heading id that does not exist fails npm run build — and therefore the CI docs job, the Docker build and the release. Link only to pages that exist (or are being written in the same change) and to headings you have checked.

The generated REST reference is linkable too: the overview is /docs/reference/api/, each operation is /docs/reference/api/operations/<operationId>/. The operationId is derived by the Go generator as lower-cased method + path with /api/v1/ → _, / → _, braces removed, : and - → _ — get_hosts, post_alerts_id_ack, put_objects_id, get_objects_id_effective_config, post_config_bundles_apply, post_check_commands_test (see Backend).

The REST API reference pages

starlight-openapi renders docs/src/assets/openapi.json into the sidebar group REST API reference (collapsed, method badges, operations labelled by their summary, in document order) under the base reference/api: one overview page plus one page per operation (currently 224 operations over 138 paths with 102 schemas). The JSON file is generated: make types dumps the spec with northplaned openapi and copies it there (besides producing web/src/types.gen.ts), and make types-check — the CI types job — fails when the committed copy differs from what the Go route registry produces. Never edit it by hand; if an endpoint’s summary or shape is wrong, fix the a.handle(...) registration or the Go type and run make types. Swagger UI on a running instance (/api/docs) and GET /api/openapi.json show the same document live. The hand-written conventions page is API overview.

llms.txt for AI assistants

starlight-llms-txt exports the manual as plain Markdown so AI assistants can read it — fitting for a product that ships its own AI agent and MCP server. With base: '/docs' the files are:

URL	Content
/docs/llms.txt	the index: project name, description, details (a pointer to /api/openapi.json and /api/docs), links to every page and to the custom sets
/docs/llms-full.txt	every page, unminified, in order
/docs/llms-small.txt	the same with note/tip asides and <details> removed and whitespace collapsed (caution/danger asides stay); exclude: ['reference/api/**'] applies to this file
/docs/_llms-txt/<slug>.txt	one file per custom set — Alarming (alarming/**), Administration and deployment (administration/**, deployment/**), API and CLI reference (reference/*); the slug is the GitHub-style slug of the label

promote: ['index*', 'getting-started/**', 'concepts/**'] sorts those first, demote: ['project/**'] last. The generated REST reference pages are not content-collection entries, so they never appear in these dumps; the spec itself is the machine-readable source for the API. The plugin requires site to be set, which it is.

Building for embedding

Command	Output
npm run build	astro build: renders every page, runs the links validator, builds the Pagefind index (dist/pagefind/), writes the sitemap and 404.html. About 39 MB — the operation pages of the REST reference dominate
npm run build:embed	astro build && node compress.mjs: the same, then gzip pre-compression in place
make docs	cd docs && npm ci --silent && npm run build:embed, then rm -rf internal/docs/dist, copy docs/dist/. → internal/docs/dist/, touch internal/docs/dist/.gitkeep

compress.mjs walks dist/ and, for every file with extension .html, .css, .js, .mjs, .json, .xml, .svg, .txt, .map or .webmanifest, writes <file>.gz (zlib level 9) and deletes the original; images, fonts and Pagefind’s .pf_* chunks are left alone. It prints [docs] pre-compressed N files: A MB → B MB — roughly 39 MB → 5 MB. go:embed stores files verbatim, so without this step the binary would grow by the full size of the HTML.

In git, internal/docs/dist/ contains only .gitkeep (/internal/docs/dist/* is ignored except that file). A plain go build therefore compiles but embeds no manual; make clean removes docs/dist and internal/docs/dist and recreates the .gitkeep.

Serving /docs/ from the binary (internal/docs)

internal/docs/docs.go embeds dist with //go:embed all:dist and is mounted in server.rootHandler at docs.Prefix (/docs/) ahead of the SPA catch-all, so the client-side router never swallows it. It is public by design — the pages hold no instance data and are what an operator reads before they can log in — and it is not behind the API middleware, so no token or cookie is involved. docs.Embedded() reports whether a real build is present.

Request	Response
GET /docs/	index.html
GET /docs/a/b/	a/b/index.html
GET /docs/a/b (and a/b/index.html exists)	308 → /docs/a/b/ so relative links inside the page resolve
GET /docs/a/b/index.html	301 → /docs/a/b/ (canonical directory form)
GET /docs/_astro/<hashed asset>	Cache-Control: public, max-age=31536000, immutable
any other existing file	Cache-Control: no-cache
unknown path	Starlight’s own 404.html with a real 404 status
anything but GET/HEAD	405 with Allow: GET, HEAD
no build embedded (only .gitkeep)	501 with the text documentation not embedded in this build — run `make docs` before building

Every file may exist verbatim or as <name>.gz. For a pre-compressed file the handler sends the .gz bytes as-is with Content-Encoding: gzip and Vary: Accept-Encoding when the client’s Accept-Encoding includes gzip, and inflates them in memory otherwise. Content-Type comes from the extension; a strong ETag (FNV-64a over the served bytes) is set, and successful responses go through http.ServeContent, which handles If-None-Match → 304, Range and HEAD. Paths are cleaned (path.Clean) so there is no traversal. The server’s 30 s request timeout and the generic security headers (X-Content-Type-Options, X-Frame-Options: DENY, Referrer-Policy, HSTS on HTTPS) still apply; only the Content-Security-Policy is the handler’s own:

default-src 'self'; script-src 'self' 'unsafe-inline' 'wasm-unsafe-eval'; style-src 'self' 'unsafe-inline'; img-src 'self' data:; font-src 'self'; connect-src 'self'; frame-ancestors 'none'; base-uri 'self'; form-action 'self'

Starlight relies on inline bootstrap scripts (theme before first paint, sidebar state) and its Pagefind search instantiates WebAssembly at runtime; the SPA’s stricter policy (hash-allow-listed inline script, the Stept origins) would block both, and the docs contain no user input, so 'unsafe-inline' and 'wasm-unsafe-eval' are the accepted trade here — everything else stays locked to the own origin, and securityHeaders skips the SPA CSP for /docs/ paths. internal/docs/docs_test.go covers the routing table, the canonical redirect, pre-compressed serving with and without Accept-Encoding, write rejection and the 501 case against an in-memory tree (HandlerFS). The headers the rest of the server sends are documented in TLS and proxying.

How the docs get shipped

Path	Step
CI (.github/workflows/ci.yml, job docs)	Node 22, cd docs && npm ci, npm run build — the quality gate: a page that does not compile or a broken link fails the job; uploads docs-dist (1 day). Runs on every push and pull request to main alongside ui, types, lint, test, e2e, postgres, cross-build
Docker image (Dockerfile, stage docs)	node:22-alpine, npm ci --legacy-peer-deps, npm run build:embed; the Go stage does COPY --from=docs /docs/dist ./internal/docs/dist before go build, so every image — including the main-<sha> images the Deploy workflow rolls to production — serves /docs/
Release (.github/workflows/release.yml)	the ui job runs npm run build:embed in docs/ and uploads docs-dist; the binaries job downloads it into internal/docs/dist before building, so the tarball binaries carry the manual too (see Release process)
Local	make docs before make build (or make all)

.dockerignore excludes docs/node_modules, docs/dist and docs/.astro, so the image always builds the docs from source.

Style rules (summary)

The binding rules for writers, condensed:

• Readers are operators, integrators and on-call engineers: Linux-fluent, no prior Northplane knowledge. English; second person; present tense; lead with what the reader wants to do, then exact commands, fields and defaults. No marketing, no filler.
• Every config key, flag, field, endpoint, default, unit and permission name comes from the code (or the research sheets distilled from it). Document real behaviour; when the code deviates from the intended behaviour, say so in a :::caution or :::note instead of describing what should work.
• Terminology: Northplane (product), northplaned (server), np (CLI), np-agent, np-gen; object = host or service; check command; alert (the domain is “alarming”); event source; channel; escalation policy; on-call schedule; contact; tenant; site (federation edge); bundle (YAML config); NP-TSDB; secret store; the instance. UI labels in English with the German label in parentheses on first use — Admin → Channels (Kanäle) — and menu paths in bold.
• Shape: tables for references, numbered steps for procedures, one copy-pasteable example per feature; reference pages complete, guides 120–400 lines; each fact has one home page and other pages link to it.
• No “verified on …” stamps except on the deployment environments page, where the date is the point; no images by writers (the lead inserts screenshots); never hand-edit docs/src/assets/openapi.json.
• Links as described above; a broken one fails the build.

Editing workflow

1. Work on a feature branch in a worktree (Development setup); create or edit the page under src/content/docs/<section>/ with the frontmatter and sidebar.order.
2. Write against the code; run make docs-dev and read the page in the browser.
3. cd docs && npm run build to catch broken links and MDX errors before pushing (or rely on the CI docs job, which runs the same build).
4. If you changed an API route or type, run make types so the REST reference and types.gen.ts follow; commit the regenerated files.
5. Open the pull request; the docs job must be green. After the merge to main, CI and the Deploy workflow build the image and the updated pages are live at /docs/ on the production instance after the rollout; the next v* tag ships them in the release binaries.
